How to Set Up Residential Proxies: Endpoint, Session, and Code

To set up a residential proxy, you need four values (host, port, username, and password) and two decisions: which protocol endpoint your client should use, and whether requests should rotate or stay on one IP. With PacketStream, the host is proxy.packetstream.io, the recommended port is 31111 for the HTTPS proxy, the username is your PacketStream username, and the password is your auth key. Add _country-US or _session-label to the auth key to target a country or keep one IP, then confirm the exit with a single test request before you point real work at it.

The checklist below covers the whole setup. The sections after it give working examples for cURL, Python, Node.js, and Playwright.

Setup checklist

Choose an endpoint

All three endpoints use the same host and credentials. Only the port and scheme change.

Supporting HTTPS websites is not the same as supporting an HTTPS proxy. If a client fails to connect on 31111, check that it can speak TLS to the proxy itself. Do not turn off certificate verification to make an error go away. The HTTPS vs. SOCKS5 guide compares the two in more depth.

Choose rotation or a sticky session

Session behavior and country targeting are both set by adding suffixes to the auth key. The host and port stay the same.

Three rules decide how this behaves in practice:

• Rotation is per connection, not per request. HTTP clients and browsers reuse open connections, and every request on one connection uses the same exit. A new connection triggers a new selection, but the IP is not guaranteed to differ. See how connection pooling affects rotation.
• A sticky session lasts while it is used. The label keeps its IP as long as it opens at least one successful new connection every 60 minutes. After 60 minutes without one, it expires and the next connection gets a new exit.
• A sticky session never moves. If the Packeter providing the IP goes offline, new connections on the label fail with 502 Proxy Error (sticky session IP is offline) (a general failure reply on SOCKS5) until that IP returns or the label expires. If the workflow cannot wait, use a new label and restart from a checkpoint.

A requested country is never swapped for another: if no exit is available there, the request fails. Use labels that contain no personal data, such as catalog42, not an email address.

Verify the proxy with cURL

Set your credentials once per shell:

export PACKETSTREAM_USER='your_username'
export PACKETSTREAM_AUTH_KEY='your_auth_key'

Send one request through the HTTPS proxy. The response shows the exit's IP address, country, and network, which should differ from your own:

curl --silent --show-error --fail-with-body \
  --connect-timeout 15 --max-time 45 \
  --proxy 'https://proxy.packetstream.io:31111' \
  --proxy-user "${PACKETSTREAM_USER}:${PACKETSTREAM_AUTH_KEY}" \
  'https://ipinfo.io'

Check a country and a sticky session the same way. Run the second command twice; both runs should report the same IP:

# United States exit, rotating
curl --silent --show-error --fail-with-body \
  --proxy 'https://proxy.packetstream.io:31111' \
  --proxy-user "${PACKETSTREAM_USER}:${PACKETSTREAM_AUTH_KEY}_country-US" \
  'https://ipinfo.io'

# Sticky session: same exit on each new connection
curl --silent --show-error --fail-with-body \
  --proxy 'https://proxy.packetstream.io:31111' \
  --proxy-user "${PACKETSTREAM_USER}:${PACKETSTREAM_AUTH_KEY}_session-setup1" \
  'https://ipinfo.io'

For SOCKS5, change the proxy to socks5h://proxy.packetstream.io:31113. To test more than one request at a time, the open-source ProxySampler tool reads the same environment variables, opens a new connection for each request, and reports errors without printing the auth key.

Python with Requests

Build the password from the auth key and any suffixes, URL-encode both credentials, and pass the proxy on every request so environment settings cannot override it:

import os
from urllib.parse import quote

import requests


def packetstream_proxy(country=None, session=None):
    password = os.environ["PACKETSTREAM_AUTH_KEY"]
    if country:
        password += f"_country-{country}"
    if session:
        password += f"_session-{session}"
    user = quote(os.environ["PACKETSTREAM_USER"], safe="")
    url = f"https://{user}:{quote(password, safe='')}@proxy.packetstream.io:31111"
    return {"http": url, "https": url}


response = requests.get(
    "https://ipinfo.io",
    proxies=packetstream_proxy(country="US"),
    timeout=30,
)
response.raise_for_status()
print(response.json())

Install Requests with python -m pip install requests. Do not print or log the proxy URL; it contains your auth key.

Node.js with Undici

Undici's ProxyAgent supports HTTPS proxy URIs. Install it with npm install undici, then:

import { ProxyAgent, fetch } from "undici";

const username = process.env.PACKETSTREAM_USER;
const authKey = process.env.PACKETSTREAM_AUTH_KEY;

if (!username || !authKey) {
  throw new Error("Set PACKETSTREAM_USER and PACKETSTREAM_AUTH_KEY");
}

// Add "_country-US" or "_session-label" here to target or stick.
const password = authKey;
const token = Buffer.from(`${username}:${password}`).toString("base64");
const dispatcher = new ProxyAgent({
  uri: "https://proxy.packetstream.io:31111",
  token: `Basic ${token}`,
});

try {
  const response = await fetch("https://ipinfo.io", {
    dispatcher,
    signal: AbortSignal.timeout(30_000),
  });
  if (!response.ok) throw new Error(`HTTP ${response.status}`);
  console.log(await response.json());
} finally {
  await dispatcher.close();
}

Playwright

Playwright takes the proxy server and credentials separately. This example keeps one exit for the whole browser run with a sticky session label:

import { chromium } from "playwright";

const browser = await chromium.launch({
  proxy: {
    server: "https://proxy.packetstream.io:31111",
    username: process.env.PACKETSTREAM_USER,
    password: `${process.env.PACKETSTREAM_AUTH_KEY}_session-browser1`,
  },
});

try {
  const page = await browser.newPage();
  await page.goto("https://ipinfo.io/json", {
    waitUntil: "domcontentloaded",
    timeout: 30_000,
  });
  console.log(JSON.parse(await page.locator("body").innerText()));
} finally {
  await browser.close();
}

Browsers reuse connections, so with the plain auth key a new page or navigation does not guarantee a new exit. The Playwright guide covers targeting, sessions, and recovery in more detail. Go, Rust, PHP, Ruby, Java, C#, Puppeteer, Selenium, Scrapy, and Crawlee examples are in the PacketStream examples repository.

Browser and operating-system proxy settings

For manual browsing, a browser or operating-system proxy dialog needs the same host and port and prompts for the username and auth key when you first connect. Many of these dialogs only accept a plain HTTP proxy. In that case, use proxy.packetstream.io on port 31112, keeping in mind that the credentials travel to the gateway unencrypted. A system-wide setting sends every application's traffic through the proxy and bills it per GB, so prefer configuring only the application that needs it.

If the test request fails

The troubleshooting docs cover each case and what to send support. When the test request works, set connect and total timeouts in your client, retry only transient failures with backoff, and you are ready to run real jobs. Not set up yet? Create an account; residential bandwidth is $1/GB with no subscription.
